Electricity meter | Alfa AS300 | Russia

DescriptionAlfa SMART AS300 is a single-phase intelligent multi-tariff electricity meter of the Alfa SMART family with an integrated PLC modem and a two-pole integrated contactor. It is used as part of automated systems for monitoring and accounting of electricity at control points for monitoring, accounting and distribution of electricity. The communication module allows you to fully use the functionality of the ALFA SMART AS300 meter and create reliable AIIS KUE systems, where counters are the basic element. AS300 is used to build commercial accounting systems in: Accounting systems (AIIS KUE) in the retail electricity market, Smart Metering Systems, Commercial and small-engine sector, Private sector for household accounting. FEATURES: The ability to use in Smart Metering Multi-tariff accounting in two directions Integrated power relay (contactor) – 100A Flexible pricing Network monitoring Maintaining load schedules Measurement and display of three-phase network parameters Self-diagnosis functions Extensive data protection features Extended event log Auto-reading The SmartSet software package is used to configure and read information from the counter. SmartSet software and technical documentation are available on the company's websites. specifications: Accuracy class: 1 (active energy), 2 (reactive energy) Maximum storage depth of hourly load profiles of active and reactive electricity in the forward and reverse direction (four metering channels): 180 days Contactor (integrated power relay): 100A Built-in PLC modem Basic (maximum) current 5 (60)A Operating voltage range: 220V±20% Temperature range: -400C... 600C Weight: 2.0 kg Overall dimensions: 230mmx132mmx65mm(HxWXT) High-strength housing: IP52 GOST 22261-94, GOST R 52320-2005, 52322-2005, 52425-2005, PRIME Alliance certificate. DLMS Protocol (D) Information and software preservation time in the absence of external power supply: 30 years Average operating time to failure: 150000h Service life: at least 30 years Interval between verifications: 16 years IN THE PACKAGE: Counter; Passport; Warranty card; User Manual; Box.more hide
