DISCONTINUED Antenna Analyzer AA-1000 RigExpert

Frequency range: 0.1 to 1000 MHz – AA-1000 Frequency entry: 1 kHz resolution Measurement for 25, 50, 75 and 100-Ohm systems SWR measurement range: 1 to 100 in numerical mode, 1 to 10 in graph mode SWR display: numerical or easily-readable bar R and X range: 0…10000, -10000…10000 in numerical mode, 0…1000, -1000…1000 in graph mode Display modes: –    SWR at single or multiple frequencies –    SWR, return loss, R, X, Z, L, C at single frequency –    SWR graph, 80 points –    R, X graph, 80 points –    Smith (or polar) chart, 80 points –    TDR (Time Domain Reflectometer) graph Optional open-short-load calibration in SWR, R,X or Smith/polar chart graph modes. RF output: –    Connector type: N –    Output signal shape: square, 0.1 to 200 MHz. For higher frequencies, harmonics of the main signal are used. –    Output power: -10 dBm (at 50 Ohm load) Power: –    Three 1.5V, alcaline batteries, type AA * –    Three 1.2V, 1800…3000 mAh, Ni-MH batteries, type AA –    Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used –    When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources Interface: –    320×240 color TFT displaty –    6×3 keys on the water-proof keypad –    Multilingual menus and help screens –    USB connection to a personal computer Dimensions: 23x10x5.5 cm (9x4x2”) Operating temperature: 0…40 °C (32…104 °F) Weight: 650g (23 Oz) Warranty: 2 years GTIN-13: 4820185420044 RigExpert AA-1000 is made in Ukraine. Specifications are subject to change without notice. * Batteries are not included with the analyzer.
